Replacement for Stabilus Lift-O-Mat 2695NA 0200N

$58.86



Out of Stock until approximately 12/3/2024.

Replacement gas spring for the Stabilus Lift-O-Mat 2695NA 0200N. This fits a (possibly already present) ball with a diameter of 10mm. A corresponding ball is included. Brand: HAHN, a Stabilus company.

Please note:
The diameter of the tube of this replacement gas spring is 23mm instead of 22mm.

View this gas spring in our configurator.

Replacement for Stabilus Lift-O-Mat 2695NA 0200N quantity

Add to basket

This gas spring is also known as CA2695NA.



This gas spring has a cylinder diameter of 23 mm. The rod has a diameter of 10 mm. The stroke of the gas spring is 400 millimeter. The total length of this gas strut is 885 mm. This is the total distance between the centers of the two mounting parts. Without the mounting parts this gas spring is 845 mm long (thread to thread). This replacement gas spring has a force of 200 Newton. This is not an official Stabilus Lift-O-Mat gas spring, but a so called replacement. This a gas spring with the brand HAHN. Nevertheless, the force and dimensions close to equal.
