Replacement for Airax Rayflex 6851254805001 500N

$53.04



Out of Stock until approximately 11/29/2024,

Replacement gas spring for the Airax Rayflex 6851254805001 500 Newton. The eye has a thickness of 10mm and a hole diameter of 8.1mm. Brand: HAHN, a Stabilus company.

Please note:

The thickness of the eye of this replacement is 10mm instead of 5mm.

The diameter of the tube of this replacement gas spring is 23mm instead of 22mm.

View this gas spring in our configurator.

Replacement for Airax Rayflex 6851254805001 500N quantity

Add to basket

This gas spring is also known as 512548 500N, 50006851254805001, 6851254805001.00.



The diameter of the cylinder of this gas spring is 23 millimeters. The cross section of the rod is 10 mm. The stroke is 400 millimeter long. In total, the length is 883 millimeter. This is the total distance between the centers of the two mounting parts. The length from thread to thread (wihout mounting parts) is 845 mm. This gas spring (6851254805001) has a force of 500 Newton. This is not an official Airax Rayflex gas spring, but a so called replacement. This a gas spring with the brand HAHN. Nevertheless, the force and dimensions almost entirely equal.
