Replacement for Airax Rayflex 6851252405501 550N

$43.06



Replacement gas spring for the Airax Rayflex 6851252405501 550 Newton. The eye has a thickness of 10mm and a hole diameter of 8.1mm. Brand: HAHN, a Stabilus company.

Please note:

The thickness of the eye of this replacement is 10mm instead of 5mm.

The diameter of the tube of this replacement gas spring is 23mm instead of 22mm.

View this gas spring in our configurator.

Replacement for Airax Rayflex 6851252405501 550N quantity

Add to basket

This gas spring is also known as 512524 550N, 50006851252405501, 6851252405501.00.



The diameter of the black cylinder of this gas spring is 23 millimeter. The diameter of the rod totals 10 mm. The stroke of the gas spring is 300 millimeter. The total length of this replacement is exactly 683 mm. This is the distance between the centers of the mounting parts. The length from thread to thread (wihout mounting parts) is 645 mm. This replacement gas spring (6851252405501) has a force of 550 Newton (N). This is not an original gas spring from Airax Rayflex, but a so called replacement gas spring. This replacement gas spring is a HAHN gas spring. Nevertheless, the force and dimensions nearly equal.
